As a new type of formwork system, the quick dismantling aluminium alloy formwork system has been in use for 50 years since its introduction in the United States in 1962. It is also widely adopted in newly industrialized countries such as Mexico, Brazil, Malaysia, South Korea, and India.
The formwork system consists of the following four components:
1. Formwork Panel System: including wall panels, slab panels, K-boards, and internal corner panels.
2. Support System: utilizing steel supports.
3. Fastening System: comprising tie rods and wall tie couplers.
4. Accessory System: including wedges and pins, among others.
We currently operate a total of more than 110 extrusion lines, ranging from 600 tons to 7,500 tons, capable of meeting the requirements for formwork profiles with fabricated panel widths ranging from 50 mm to 600 mm. The material used is 6061-T6 aluminium alloy, produced from high-purity aluminium ingots to ensure compliance with chemical composition standards as well as mechanical properties such as strength and hardness. In addition, we have established a CNC machining workshop to provide comprehensive deep processing services, including cutting, drilling, punching, milling, welding, and bending, among others.
| Temper and alloy | 6061-T6 |
| Series number | Construction formwork |
| Further processing | Cutting,welding,punching,drilling |
| Surface treatment | Painted Coated |
| Usage | Aluminium concrate wall ,beam slab ,corner |
| Color | Mill finish powder coated |
| Certificate | ISO9001:2008 |
| Packing | Packing in bundles |
| Seaport | Qingdao ,Tianjin |
| Lead time | 35days |
| Warranty | One year |
Nine Benefits of Using Aluminium Formworks:
1. Shortage of on-site construction space
2. High reuse rate, which effectively reduces the average cost
3. Construction can be carried out more easily, conveniently, and efficiently
4. Excellent structural stability and high load-bearing capacity
5. A smoother concrete surface after formwork removal
6. Minimal construction waste left on site
7. Standardized design with wide versatility and low carbon emissions
8. Environmentally friendly
9. A simplified and efficient support system
